1. Installing of OS Centos 6.3 on each of servers and configure interfaces.
2. Adding necessary repositories on each server
2.1. EPEL
wget http://mirror.yandex.ru/epel/6/x86_64/epel-release-6-8.noarch.rpm (check actual package version before)
rpm -i epel-release-6-8.noarch.rpm
2.2 squid-repo
Squid 3.1 is a standard version which include in Centos 6.3. If http/1.1 answers is needed than squid 3.2 is required.
Follow the official site information and add squid repo
cat /etc/yum.repos.d/squid.repo
[squid]
name=Extra Packages squid proxy for Centos 6
baseurl=http://repo.ngtech.co.il/rpm/centos/6/x86_64/
enabled=1
gpgcheck=0
3. Updating OS and installing squid and other packages on each server.
yum update
reboot (if needed)
yum install htop systat blktrace scp ntp bind bind-utils pacemaker corosync make gcc \
gcc-c++ openssl-devel openssh-clients squid
4. Configuring local NTPD on each server
/etc/ntp.conf
driftfile /var/lib/ntp/drift
restrict default kod nomodify notrap nopeer noquery
restrict -6 default kod nomodify notrap nopeer noquery
restrict 127.0.0.1
restrict -6 ::1
server your_1.ntp.server
Setting starting service at boot and start
chkconfig ntpd on
service ntpd start
5. Configuring local DNS - cache server on each proxy node
cat /etc/named.conf
//
// named.conf
//
// Provided by Red Hat bind package to configure the ISC BIND named(8) DNS
// server as a caching only nameserver (as a localhost DNS resolver only).
//
// See /usr/share/doc/bind*/sample/ for example named configuration files.
//
options {
listen-on port 53 { 127.0.0.1; };
listen-on-v6 port 53 { ::1; };
directory "/var/named";
dump-file "/var/named/data/cache_dump.db";
statistics-file "/var/named/data/named_stats.txt";
memstatistics-file "/var/named/data/named_mem_stats.txt";
recursion yes;
/* Path to ISC DLV key */
bindkeys-file "/etc/named.iscdlv.key";
managed-keys-directory "/var/named/dynamic";
max-ncache-ttl 3600;
max-cache-ttl 28800;
allow-query { any; };
allow-recursion { any; };
forwarders { **your_dns_server1**; **your_dns_server2**; };
};
logging {
channel default_debug {
file "data/named.run";
severity dynamic;
};
};
zone "." IN {
type hint;
file "named.ca";
};
include "/etc/named.rfc1912.zones";
include "/etc/named.root.key";
Set nameserver
cat /etc/resolv.conf
nameserver 127.0.0.1
6. Installing Delegate on proxy-node1 an proxy-node2
6.1 Downloading final stable version http://www.delegate.org/delegate/download/ and unpacking.
6.2 Compile with make
6.3 Copy binary delegated from /usr/src/delegatex.x.x/src/delegate to /usr/sbin directory three times for each protocols
cp delegated /usr/sbin/delegated-imap
cp delegated /usr/sbin/delegated-smtp
cp delegated /usr/sbin/delegated-ftp
6.4 Creating scripts
FTP
cat /etc/init.d/delegate-ftp
#!/bin/sh
# Startup script for anacron
#
# chkconfig: 34 60 40
# description: Run Delegate daemons
. /etc/init.d/functions
prog="delegated-ftp"
startoptions="-r -P0.0.0.0:21 SERVER=ftp ADMIN=adm@your_domain.dom \
CACHE=no REMITTABLE=ftp,ftps PERMIT=*:*:192.168.* MAXIMA=delegated:100,standby:80 \
TIMEOUT=shutout:300,restart:1d,acc:100,con:100,dns:4,dnsinv:1 \
RESOLV=sys,file SRCIF=217.9.80.9:*:* LOGFILE=ftp[date+.%d]"
stopoptions="-P0.0.0.0:21 -Fkill"
lockfile=/var/lock/subsys/$prog
start() {
echo -n $"Starting $prog: "
#
daemon $prog $startoptions
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && touch $lockfile
return $RETVAL
}
stop() {
echo -n $"Stopping $prog: "
#
daemon $prog $stopoptions
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && rm -f $lockfile
return $RETVAL
}
case "$1" in
start)
start
;;
stop)
stop
;;
status)
status $prog
;;
restart)
stop
start
;;
*)
echo $"Usage: $0 {start|stop|restart|status}"
exit 1
esac
exit 0
chmod 755 /etc/init.d/delegate-ftp
IMAP
For YANDEX
cat /usr/sbin/delegate-imapo
#!/bin/sh
/usr/sbin/delegated-imap -r -P0.0.0.0:143 SERVER=imap ADMIN=adm@your_domain.dom SRCIF=217.9.80.9:*:* CACHE=no \
REMITTABLE=imap,imaps PERMIT=*:*:192.168.* STLS=fsv MOUNT="//*%S/%S imaps://imap.yandex.ru/*%(1)@%(0)" LOGFILE="imap[date+.%d]"
For GOOGLE
cat /usr/sbin/delegate-imapo
#!/bin/sh
/usr/sbin/delegated-imap -r -P0.0.0.0:143 SERVER=imap ADMIN=adm@your_domain.dom SRCIF=217.9.80.9:*:* CACHE=no \
REMITTABLE=imap,imaps PERMIT=*:*:192.168.* STLS=fsv MOUNT="//*%S/%S imaps://imap.gmail.com/*%(1)@%(0)" LOGFILE="imap[date+.%d]"
chmod 755 /usr/sbin/delegated-imapo
Tuning Gelegate
If you will face with heavy duty problems just tune MAXIMA parameters.
For example MAXIMA=listen:50,delegated:300
cat /etc/init.d/delegate-imap
#!/bin/sh
# Startup script for anacron
#
# chkconfig: 34 60 40
# description: Run Delegate daemons
. /etc/init.d/functions
prog="delegated-imap"
progo="delegated-imapo"
stopoptions="-P0.0.0.0:143 -Fkill"
lockfile=/var/lock/subsys/$prog
start() {
echo -n $"Starting $prog: "
#
daemon $progo
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && touch $lockfile
return $RETVAL
}
stop() {
echo -n $"Stopping $prog: "
#
daemon $prog $stopoptions
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && rm -f $lockfile
return $RETVAL
}
case "$1" in
start)
start
;;
stop)
stop
;;
status)
status $prog
;;
restart)
stop
start
;;
*)
echo $"Usage: $0 {start|stop|restart|status}"
exit 1
esac
exit 0
chmod 755 /etc/init.d/delegate-imap
SMTP
For YANDEX
cat /usr/sbin/delegate-smtpo
#!/bin/sh
/usr/sbin/delegated-smtp -r -P0.0.0.0:25 SERVER=smtps://smtp.yandex.ru/ CACHE=no REMITTABLE=* CACHE=no PERMIT=*:*:192.168.* \
LOGFILE="smtp[date+.%d]" STLS=fsv SRCIF=217.9.80.9:*:*
For GOOGLE
cat /usr/sbin/delegate-smtpo
#!/bin/sh
/usr/sbin/delegated-smtp -r -P0.0.0.0:25 SERVER=smtps://smtp.gmail.com/ CACHE=no REMITTABLE=* CACHE=no PERMIT=*:*:192.168.* \
LOGFILE="smtp[date+.%d]" STLS=fsv SRCIF=217.9.80.9:*:*
chmod 755 /usr/sbin/delegated-smtpo
Tuning Delegate
If you will face with heavy duty problems just tune MAXIMA parameters.
For example MAXIMA=listen:50,delegated:300
cat /etc/init.d/delegate-smtp
#!/bin/sh
# Startup script for anacron
#
# chkconfig: 34 60 40
# description: Run Delegate daemons
. /etc/init.d/functions
prog="delegated-smtp"
progo="delegated-smtpo"
stopoptions="-P0.0.0.0:25 -Fkill"
lockfile=/var/lock/subsys/$prog
start() {
echo -n $"Starting $prog: "
#
daemon $progo
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && touch $lockfile
return $RETVAL
}
stop() {
echo -n $"Stopping $prog: "
#
daemon $prog $stopoptions
RETVAL=$?
echo
[ $RETVAL -eq 0 ] && rm -f $lockfile
return $RETVAL
}
case "$1" in
start)
start
;;
stop)
stop
;;
status)
status $prog
;;
restart)
stop
start
;;
*)
echo $"Usage: $0 {start|stop|restart|status}"
exit 1
esac
exit 0
chmod 755 /etc/init.d/delegate-smtp
6.5. Starting delegated on both servers.
Because delegated is very stable application you can just start it on both proxy servers. (I'm using delegate more the seven years)
chkconfig delegate-ftp on
chkconfig delegate-smtp on
chkconfig delegate-imap on
service delegate-ftp start
service delegate-smtp start
service delegate-imap start
Use cron for restart services once a week for log rotation (not more often than once a day without changing of LOGFILE=“protocol[date+.%d]”)
7. Configuring squid on each server
Detail configuration will not describe. For detail configuration try out this link.
For this example:
cat /etc/squid/squid.conf
acl localhost src 127.0.0.1/32 ::1
#acl localnet src 10.0.0.0/8 # RFC1918 possible internal network
#acl localnet src 172.16.0.0/12 # RFC1918 possible internal network
acl localnet src 192.168.0.0/24 # RFC1918 possible internal network
#acl localnet src fc00::/7 # RFC 4193 local private network range
#acl localnet src fe80::/10 # RFC 4291 link-local (directly plugged) machines
acl CONNECT method CONNECT
shutdown_lifetime 3 second
http_access allow manager localhost
http_access deny manager
http_access allow localnet
http_access allow localhost
# And finally deny all other access to this proxy
http_access deny all
http_port 8080
tcp_outgoing_address 217.9.80.9
hierarchy_stoplist cgi-bin ?
cache_mem 2048 MB
maximum_object_size_in_memory 2048 KB
# Leave coredumps in the first cache dir
coredump_dir /var/spool/squid
# Add any of your own refresh_pattern entries above these.
refresh_pattern . 0 20% 240
Remove starting at boot
chkconfig squid off
8. Configuring Corosync on each server
cat /etc/corosync/corosync.conf
compatibility: whitetank
totem {
version: 2
secauth: on
threads: 0
interface {
ringnumber: 0
bindnetaddr: 192.168.0.N # where N is IP address of front end network
mcastaddr: 226.94.1.1
mcastport: 5405
ttl: 1
}
}
logging {
fileline: off
to_stderr: no
to_logfile: yes
to_syslog: yes
logfile: /var/log/cluster/corosync.log
debug: off
timestamp: on
logger_subsys {
subsys: AMF
debug: off
}
}
amf {
mode: disabled
}
cat /etc/corosync/service.d/pcmk
service {
# Load the Pacemaker Cluster Resource Manager
name: pacemaker
ver: 1
}
END
Create authkey on one server and copy it to another servers.
corosync-keygen.
Restart services
service corosync restart
service pacemaker restart
Check
crm status
Last updated: Fri Jan 11 09:31:55 2013
Last change: Tue Dec 11 14:33:11 2012 via crm_resource on proxy-node1
Stack: openais
Current DC: proxy-node1 - partition with quorum
Version: 1.1.7-6.el6-148fccfd5985c5590cc601123c6c16e966b85d14
3 Nodes configured, 3 expected votes
============
Online: [ proxy-node1 proxy-node2 proxy-quorum ]
9. Configuring pacemaker
On one proxy node
crm
crm(live)#
crm(live)#configure
crm(live)configure#crm configure property no-quorum-policy=stop
crm(live)configure#crm configure property stonith-enabled=false
crm(live)configure#primitive LShareIP ocf:heartbeat:IPaddr2 params ip="192.168.0.9" cidr_netmask="23" op monitor interval="30s" on_fail="standby"
crm(live)configure#primitive GShareIP ocf:heartbeat:IPaddr2 params ip="217.9.80.9" cidr_netmask="24" op monitor interval="30s" on_fail="standby"
crm(live)configure#primitive squid lsb:squid op monitor interval="120s" on_fail="standby" \
op start interval="0" timeout="120s" \
op stop interval="0" timeout="120s"
crm(live)configure#commit
On one quorum node
crm
crm(live)#node
crm(live)node#standby
Starting at boot
chkconfig corosync on
chkconfig pacemaker on
10. Configuring iptables
cat /etc/sysconfig/iptables
# Firewall configuration written by system-config-firewall
# Manual customization of this file is not recommended.
*filter
:INPUT ACCEPT [0:0]
:FORWARD ACCEPT [0:0]
:OUTPUT ACCEPT [0:0]
-A INPUT -i eth0 -m state --state ESTABLISHED,RELATED -j ACCEPT
-A INPUT -i eth0 -p icmp -j ACCEPT
-A INPUT -i eth0 -j DROP
COMMIT
eth0 is external interface.
service iptables restart
chkconfig iptables on
